| ZWCAD+ 2014 | AutoCAD 2014 | ||||
|---|---|---|---|---|---|
| Std | pro | Mechanical | LT | Full | |
| Compalibility & Collaberation | |||||
| Dual-core utilization | ○ | ○ | ○ | ○ | ○ |
| .dwg for AutoCAD version 2.5 to 2014 | ○ | ○ | ○ | ○ | ○ |
| DWF/ DXF/ DWT support | ○ | ○ | ○ | ○ | ○ |
| passwork lock/ unlock drawings | ○ | ○ | ○ | ○ | ○ |
| eTransmit | ○ | ○ | ○ | ○ | ○ |
| Interface | |||||
| Ribbon | ○ | ○ | ○ | ○ | ○ |
| CUI | ○ | ○ | ○ | ○ | ○ |
| Palettes | ○ | ○ | ○ | ○ | ○ |
| Design center | ○ | ○ | ○ | ○ | ○ |
| Menu and Toolbar | ○ | ○ | ○ | ○ | ○ |
| Command line with autocomplete | ○ | ○ | ○ | ○ | ○ |
| Drawing tabs switching | ○ | ○ | ○ | ||
| Smart Peek | ○ | ○ | ○ | ○ | ○ |
| SmartMouse | ○ | ○ | ○ | ||
| Annotate | |||||
| Dimensions | ○ | ○ | ○ | ○ | ○ |
| Quick Dimension | ○ | ○ | ○ | ○ | ○ |
| Associative dimentions | ○ | ○ | ○ | ○ | ○ |
| Leader & Qleader | ○ | ○ | ○ | ○ | ○ |
| Table(Import&export, table style) | ○ | ○ | ○ | ○ | ○ |
| Text and Mtext | ○ | ○ | ○ | ○ | ○ |
| Revcloud | ○ | ○ | ○ | ○ | ○ |
| Text in-place editing | ○ | ○ | ○ | ○ | ○ |
| Hatch/ Gradient Hatch | ○ | ○ | ○ | ○ | ○ |
| Raster Image management | ○ | ○ | ○ | ○ | |
| Image polygonal clip | ○ | ○ | ○ | ○ | |
| Support Image Of ECW and JPEG2000 | ○ | ○ | ○ | ○ | ○ |
| Spelling | ○ | ○ | |||
| Tables & Table styles | ○ | ○ | ○ | ○ | ○ |
| Field | ○ | ○ | ○ | ○ | ○ |
| Layer | |||||
| Layer manager | ○ | ○ | ○ | ○ | ○ |
| Layer filter | ○ | ○ | ○ | ○ | ○ |
| Layer state manager | ○ | ○ | ○ | ○ | ○ |
| Layer translator | ○ | ○ | ○ | ○ | |
| Layer previous | ○ | ○ | ○ | ○ | ○ |
| Xref, Block and attribute | |||||
| OLE | ○ | ○ | ○ | ○ | ○ |
| Image | ○ | ○ | ○ | ○ | ○ |
| Xrefs in-place editing | ○ | ○ | ○ | ○ | ○ |
| Multiple block inserting | ○ | ○ | ○ | ○ | |
| Dynamic block(BEDIT unavaliable) | ○ | ○ | ○ | ○ | ○ |
| Battman | ○ | ○ | ○ | ○ | ○ |
| 3D | |||||
| Full ACIS modeling & editing | ○ | ○ | ○ | ||
| ACIS viewing | ○ | ○ | ○ | ||
| 3D Orbit | ○ | ||||
| Rendreing | ○ | ○ | ○ | ○ | ○ |
| Visual Styles(Hide&Shde) | ○ | ○ | ○ | ○ | |
| Programming | |||||
| Active X, including in-place editing | ○ | ○ | ○ | ○ | |
| Full LISP support with vl-, vlr-, vla-, and vlax- support | ○ | ○ | ○ | ○ | |
| Visual basics for Applications (VBA) | ○ | ○ | ○ | ||
| .NET | ○ | ○ | ○ | ||
| Script recorder | ○ | ○ | ○ | ||
| DCL engine | ○ | ○ | ○ | ○ | |
| COM API (AutoCAD COM) | ○ | ○ | ○ | ○ | |
| Runtime Extension(ZRX/ARX) | ○ | ○ | ○ | ○ | |
| Full Diesel expression | ○ | ○ | ○ | ○ | ○ |
| MNU, MNS, and MNL file support | ○ | ○ | ○ | ○ | ○ |
| Printing | |||||
| CTB & STB table files | ○ | ○ | ○ | ○ | ○ |
| Ploting | ○ | ○ | ○ | ○ | ○ |
| publish | ○ | ○ | ○ | ○ | ○ |
| Export | ○ | ○ | ○ | ○ | ○ |
| Viewport(VPMAX) | ○ | ○ | ○ | ○ | ○ |
| MVSETUP | ○ | ○ | ○ | ○ | |
| shade plot | ○ | ○ | ○ | ○ | ○ |
| Layout printing with different viewports | ○ | ○ | ○ | ○ | ○ |
| Others | |||||
| Cycle Select | ○ | ○ | ○ | ○ | ○ |
| Match property (Cross drawings) | ○ | ○ | ○ | ○ | ○ |
| Group | ○ | ○ | ○ | ○ | ○ |
| File Comapre | ○ | ○ | ○ | ||
| Quick Select | ○ | ○ | ○ | ○ | ○ |
| Multiline and mutiline style | ○ | ○ | ○ | ○ | |
| Region | ○ | ○ | ○ | ○ | |
| Offset | ○ | ○ | ○ | ○ | ○ |
| snap | ○ | ○ | ○ | ○ | ○ |
| mutiple undo/ redo | ○ | ○ | ○ | ○ | ○ |
| Parametric drawing | ○ | ||||
| Express tools | ○ | ○ | ○ | ○ | |
| Associative BOM | ○ | ||||
| Super edit by clicking the object | ○ | ||||
| standardlized and customizable title block | ○ | ||||
| Part library and Shaft/ Gear Generator | ○ | ||||
| Annotaion Symbols | ○ | ||||
| Jigsaw print | ○ | ||||
| Mechanicla Draw and Contsruction tools | ○ | ||||
| Team vault | ○ | ||||
| Associative Detail View | ○ | ||||
